Conical tank 200l conic 60°

SKU: 9001091
EAN: 2000000022284
Unit: pc
Stock qty: On special order

Delivery time: Eritellimustoode / Please contact / Ota yhteyttä
Price:
3310,00 €
Qty.: - +
   - or -

Stainless Steel Conical Tank for Wine and Juice Fermentation 2.5bar

High-quality stainless steel conical tank ideal for pressure fermentation and storage of wine and juice. Made from 2mm EN 1.4301 (AISI 304) stainless steel, ensuring durability and hygiene.

Main Tank Specifications:

  • Diameter: 565 mm
  • Total height: 2220 mm
  • Conical bottom: 60°
  • Maximum working pressure: 2.5 bar

Standard Equipment:

  • Precise pressure valve (2.5-3 bar)
  • Built-in thermometer
  • Efficient rotating CIP cleaning head
  • DN40 bottom outlet
  • DN25 cone center outlet
  • Top hatch (Ø300mm)

Available Accessories:

  • Precise level sensor
  • Adjustable support legs
  • Output valve
  • Drain valve
  • Bottom cleaning hatch
  • Thermal insulation

Note: Actual tank size may vary up to 10% due to technical specifications.

Keywords: wine tank, conical tank, fermentation vessel, juice tank, stainless steel tank, pressure vessel, CIP cleaning system, wine vessel

Weight (kg) 0.000000
High (m) 0
Width (m) 0
Length (m) 0
