Conical tank 300l with cooling shirt, 60°cone base
Professionals recommend - producers prefer!
EAN: 2000000052755
Unit: pc
Stock qty: On special order
Delivery time: Eritellimustoode / Please contact / Ota yhteyttä
Delivery time within Estonia for stock items approx. 3-5 working days. NOTE! Due to the rapid price increase, prices for non-stock items may change without prior notice! Standard prices with 22% VAT.
Stainless Steel Pressure Tank 500L with Cooling Jacket - Industrial Conical Vessel
High-quality conical pressure tank, manufactured from AISI304 (1.4301) stainless steel. Interior mirror polished (BA/IIId) and exterior with circular polished finish.
Technical Specifications:
- Tank cone: 60 degrees
- Maximum pressure: 5 bar
- Diameter: 636 mm
- Total height: 2100 mm
- Height H1: 1250 mm
- Height H2: 800 mm
- Z-dimension: 700 mm
- Y-dimension: 150 mm
Standard Equipment:
- Cooling jacket on vessel and cone
- 4 cooling/heating connections (½'')
- Bottom and top outlet (DN40)
- Thermometer
- Sampling valve (DN15)
- Cleaning head with pipe (DN25) and blank nut
- Top manway Ø400 mm
Available Accessories:
- Ball or butterfly valves (DN, TC)
- Bottom valve (¾'')
- Safety valve
- Level gauge (DN15 - Ø16 mm, closed type)
- Lifting lugs
- Type plate
- Oval manway (345 x 455 mm)
- Adjustable legs
Note: Actual tank volume may vary +/-10%
