Cone tank 150l with floating lid, 60° cone base

SKU: 1329
EAN: 20000000538910
Unit: pc
Stock qty: On special order

Delivery time: Eritellimustoode / Please contact / Ota yhteyttä
Price:
940,00 €
Qty.: - +
   - or -

Professional Stainless Steel Fermentation Tank

High-quality AISI 304 stainless steel (18/10 food grade) fermentation tank, ideal for wine and other liquid food fermentation.

Main Features:

  • Food safety compliant construction
  • 60° conical bottom for efficient sediment removal
  • TIG-welded finish for easy cleaning
  • Integrated stable base
  • Floral pattern exterior surface

Technical Details:

  • Stainless steel air float (∅ 480 mm)
  • Air chamber (∅ 500 mm)
  • Stainless steel pump
  • Ventilation valve (1"1/4)
  • Two ball valves:
    • 1" for complete drainage
    • 1/2" for sediment-free liquid removal

Dimensions:

  • Cylinder height: 600 mm
  • Total height of cylinder and conical bottom: 1050 mm
  • Tank diameter: 510 mm
  • Overall dimensions: 650x650x1610 mm (height)

Keywords: fermentation tank, stainless steel, wine tank, AISI 304, food fermentation, conical bottom, air float, fermentation vessel

Weight (kg) 0.000000
High (m) 1.61
Width (m) 0.65
Length (m) 0.65
