Hydraulic fork loader for tractor, rear-mounted

Hydraulic fork lift for tractor, rear-mounted

The hydraulic fork lift for tractor is designed for loading and unloading goods placed on pallets, in containers and boxes, and for transporting them over short distances. The loader is a device mounted on the three-point linkage system (TUZ), designed for 0.6-0.9T class tractors with external hydraulic output (single-acting cylinder). Maximum lifting height is 2.4 m and the maximum lifting capacity is 700 kg.

The hydraulic fork lift consists of two main components: the lifting mechanism and loader frame, and the cross bar of the tractor's three-point linkage system. The lifting mechanism consists of outer guide, inner guide, fork plate, lifting forks, piston cylinder, and lifting cable. The frame consists of steel frame construction, supports (left and right), and double-acting piston cylinder. Components required for hydraulic system installation are supplied separately.

The product is delivered directly from manufacturer's warehouse and transport cost is calculated in the shopping cart.

The device is easy to use - it attaches to the tractor's three-point linkage system and connects to the tractor's hydraulic system. The loader enables lifting and transporting heavy cargo boxes or pallets, moving them to the required location. The lateral hydraulic shift device allows the forks to move sideways, enabling more precise positioning when handling cargo.

Technical parameters:
Model: PHW-240/T
Machine type: Mounted on tractor TUZ
Weight: 310 kg
Lifting capacity: 700 kg
Lifting height: 240 cm
Fork spacing: 26-90 cm (adjustable)

Overall dimensions:
Length: 45 cm
Width: 96 cm
Height: 176 cm
