Stainless Steel Conical Tank 1000L with Adjustable Legs

Industrial 1000L stainless steel conical tank is a perfect solution for professional liquid storage and processing. The tank features a 60° conical bottom, ensuring efficient liquid flow and easy cleaning. For convenient maintenance, the tank has a 400 mm diameter inspection hatch and rounded top.

Main features of the tank:

  • Complete insulation in both cylinder and bottom sections
  • Reassembly pipe with ball valve
  • CO2 tank mounting system
  • Full and partial drainage options
  • Adjustable legs for stable installation

The tank is ideal for:

  • Food industry
  • Beverage production
  • Chemical industry
  • Liquid storage in controlled environment

Technical Specifications

Internal diameter:1150 mm
Insulation thickness:60 mm
External diameter:1270 mm
Internal coil height:750 mm
Working volume:1000 liters
Total capacity:1300 liters
Wall thickness:4 mm
Inspection hatch diameter:400 mm
External surface finish:SB (brushed stainless steel)

A mobile level meter is available as additional equipment for precise liquid level monitoring. The tank's adjustable legs allow stable installation even on uneven surfaces.

Keywords: conical tank, stainless steel tank, liquid storage, food tank, insulated tank, 1000L tank, beverage production tank, industrial tank

Weight (kg) 0.000000
High (m) 0
Width (m) 0
Length (m) 0
