Isobaric filler RLV2-iSo + rinser + CO2 pre

Semi-Automatic Yogurt Filling Line in Stainless Steel Modern Italian-made yogurt filling, capping, and marking equipment that combines precision and reliability. The heart of the machine is smart angular rotary table technology. Technical Features: AISI 316 stainless steel compliant with food industry standards, temperature-resistant, food-grade certified seals, spacious 30-liter yogurt tank, precisely adjustable dispenser (100-1000ml), foam-free bottom-up bottle filling system. Automated Processes: Adjustable speed pneumatic dosing, automatic cap feeding and securing, precise date and batch marking on caps. Practical Design: Easy cleaning system with clamp fittings, compact dimensions: 1100 x 700 x 2000mm (H), machine weight: 150 kg.

Semi-automatic bottle filling machine up to 600 bottles per hour High-quality Italian manufacturer's semi-automatic bottle dispenser-filler, ideal for filling various viscous liquids. The device can fill both room temperature and hot liquids. Main features: Filling volume: 40-1000ml Production capacity: up to 600 bottles per hour Suitable for yogurt, jam, honey, sauces, and creams Integrated capper for screw-cap bottles Technical equipment: Stainless steel frame with adjustable feet 2-meter bottle feeding conveyor with collection table Volumetric dosing pump Stainless steel dispenser with anti-drip nozzle Deflon-sealed system Pneumatic stopper system Additional information: The filling and cap closing process is automated. The operator's task is to place caps on bottles between the two operations. The capper operates with pneumatic air pressure, at low RPM, and with adjustable power. Note! Printer not included.

Automatic Beer Bottling Multiblock - For Precise and Efficient Production This modern multiblock system allows one operator to perform the entire bottling process, including container rinsing, isobaric filling (with +/-2mm accuracy) and crown capping. Main Features: Suitable for carbonated beverages, especially beer. Designed for glass bottles. 6 filling valve system. Single-stage 6-head rinsing system. Crown cap Ø 26 mm. Production capacity: up to 1200 bottles/hour (330 ml). Technical Specifications: Filling temperature: 0-2°C. Rotation direction: clockwise. Dimensions: 2065x1444x2100mm (H). Required floor space: 6000x2800mm. Food industry standard: AISI316 stainless steel. Additional Equipment: Sterile filtration system. Additional conveyors for single-operator operation. Adjustment kit for different bottle sizes. CO2 dosing system. Automatic foam removal system. Feed pump for filling line. Remote control capability via internet. Labeling device for two labels and neck label application.

Semi-Automatic Carbonated Beverage Filling System Professional Italian-made semi-automatic filling system, ideal for small producers and beverage industries. The device is designed for filling carbonated beverages (beer, cider, sparkling wine, carbonated water). Technical Specifications: 4 filling nozzles with foam reduction technology, Maximum filling pressure: 5 bar, Power consumption: 0.37kW/220V, Compressed air requirement: 120l/min/6bar, 24V, Device dimensions: 1.92m x 0.8m x 0.40m. Bottle Parameters: Maximum height: 350mm, Maximum diameter: 120mm. Basic Package Includes: Automatic filling system, Safety door, Adjustable filling level tubes, Seal kit for 1" connection valve. Additional Equipment and Features: Pneumatic filling pump, CO2 pre-injection system for foam-free filling, Cleaning solution recirculation system, Automatic cap feeding system, Oxygen removal through water spray during capping, Integrated tank cleaning system, Cleaning mode bottle dummies, Backflow prevention.

Fully automatic isobaric filling line for bottles and cans The compact rotary multiblock filling system enables efficient isobaric filling for both metal cans and glass bottles. The integrated solution includes a modern crown capping device and can sealing mechanism in a single rotating column. Main features of the equipment: Fully automated work process, compact rotary design, unified filling system for bottles and cans, energy-efficient operation mode, small footprint. The intelligently optimized construction of the filling line ensures maximum productivity with minimal energy costs. The equipment is ideally suited for smaller production spaces where efficient use of space is important.

NB! Tegemist on kasutatud tootega! Kvaliteetne Itaalias toodetud jogurti villimis-, korkimis- ja markeerimisseade multiblokktehnoloogiaga. Seade on poolautomaatne ja töötab nurkelise pöörleva tööpinna põhimõttel. Kõik tootega kokkupuutuvad osad on valmistatud roostevabast terasest AISI 316. Villimisotsiku tihendid on vastupidavad, vastavad toiduainetööstuse nõuetele ning taluvad kõrgeid temperatuure. Seadme puhastamine on lihtne tänu kergesti avatavate klambritega konstruktsioonile. Villimine ehk pudeli täitmine toimub pudeli põhjast, mis väldib vahu teket. Seadme tööprotsess algab pudelite manuaalse pealeandmisega, millele järgneb automaatne pneumaatiline doseerimine ühe dosaatoriga, mis on astmeliselt reguleeritav vahemikus 100-1000 ml. Villimiskiirus on reguleeritav ning jogurtipaagi maht on 30 L. Seade on varustatud automaatse korgi etteandja ja pealepanijaga koos pingutajaga ning pneumaatilise printeriga kuupäeva ja partii märgistamiseks korgi peale. Seadme mõõtmed on 1100 x 700 x 2000 mm (kõrgus), toitepinge 380V, 50/60Hz 3P+N+T, võimsus maksimaalselt 1 kW. Suruõhu tarbimine on 15 NL/tsükkel (6 bar) ja standardne töörõhk 6 bar. Seade kaalub 150 kg ning suudab töötada tootmisvõimsusega 4 tsüklit minutis. Seadmega saab kasutada plastpudeleid mahuga kuni 1 L, mis võivad olla varustatud kas keermega või kroonkorgiga. Seade on mõeldud jogurtitootjatele, kes vajavad poolautomatiseeritud villimislahendust keskmise tootmismahu juures, võimaldades täpset doseerimist, korgi pealepanekut ja märgistamist ühes kompaktses süsteemis.

Automatic 8-head filling machine for carbonated beverages Perfect solution for small and medium-sized soft drink manufacturers - a compact monoblock filling machine. The device is equipped with 8 precise filling nozzles on a rotating base, ensuring uniform and rapid filling process. Main features: Automatic filling system for lightly carbonated drinks 8 filling nozzles ensure optimal production speed Integrated automatic capping system for DN26mm caps Vibrating cap feeding system for smooth operation Bottle transport line with collection system Technical information: Compact monoblock construction Rotating filling base ensures uniform filling Suitable for filling various soft drinks Easy to clean and maintain The machine is an ideal choice for manufacturers who need a reliable and efficient filling solution. Thanks to its compact design, it's also suitable for facilities with limited production space.

6-Nozzle Isobaric Filling Machine - Professional Solution for Beverage Filling High-quality Italian isobaric filling machine that enables precise and efficient filling process. The device is specially designed for filling carbonated beverages, including beer, cider, sparkling wine, and carbonated water. Technical Specifications Maximum filling pressure: 5 bar Power consumption: 0.37 kW/220V Compressed air consumption: 120 l/min/6 bar Control voltage: 24V Dimensions: height 1.92 m, width 0.8 m, depth 0.40 m Bottle Parameters Maximum bottle height: 350 mm Maximum bottle diameter: 120 mm Available Accessories Automatic filling system Pneumatic pump system Container cleaning system (water and air or air only) Professional corking device 1" connection valve seal kit Adjustable filling pipes Cleaning process bottle dummies Back-flow valve The machine is equipped with foam-reducing nozzles, ensuring quality filling results. A professional filling solution ideal for small producers and medium-sized enterprises.

Automatic Beer Bottling Multiblock - For Precise and Efficient Production This modern multiblock system allows one operator to perform the entire bottling process, including container rinsing, isobaric filling (with +/-2mm accuracy) and crown capping. Main Features: Suitable for carbonated beverages, especially beer. Designed for glass bottles. 6 filling valve system. Single-stage 6-head rinsing system. Crown cap Ø 26 mm. Production capacity: up to 1200 bottles/hour (330 ml). Technical Specifications: Filling temperature: 0-2°C. Rotation direction: clockwise. Dimensions: 2065x1444x2100mm (H). Required floor space: 6000x2800mm. Food industry standard: AISI316 stainless steel. Additional Equipment: Sterile filtration system. Additional conveyors for single-operator operation. Adjustment kit for different bottle sizes. CO2 dosing system. Automatic foam removal system. Feed pump for filling line. Remote control capability via internet. Labeling device for two labels and neck label application.

Automatic Filling Machine for Small Producers - Precise and Reliable Solution A compact and efficient filling machine specifically designed for small producers who work with bottling beer, soft drinks, cider, wine, or water. The device can fill both glass and PET bottles with volumes from 200 ml to 2 liters. Main Features of the Filling Machine Available in models with 4, 6, or 8 filling nozzles Automatic filling volume calibration Precise dosing system Suitable for different bottle types Additional Equipment for Production Line Carbonation equipment for beverage gasification Bottle capping equipment Cooling systems Labeling machines Bottle rinsing and washing equipment Pasteurization equipment All equipment is made from quality materials and meets the high hygiene requirements of the food industry. Using the filling machine ensures consistent quality and efficient production process.

Fully automatic isobaric filling line for bottles and cans The compact rotary multiblock filling system enables efficient isobaric filling for both metal cans and glass bottles. The integrated solution includes a modern crown capping device and can sealing mechanism in a single rotating column. Main features of the equipment: Fully automated work process, compact rotary design, unified filling system for bottles and cans, energy-efficient operation mode, small footprint. The intelligently optimized construction of the filling line ensures maximum productivity with minimal energy costs. The equipment is ideally suited for smaller production spaces where efficient use of space is important.
