Filler DANA API MATIC 2000+ adjustable, with rotary table + 10l funnel
.png){kind=small}
Professionals recommend - producers prefer!
EAN: 20000000539573
Unit: pc
Stock qty: On special order
Delivery time within Estonia for stock items approx. 3-5 working days. NOTE! Due to the rapid price increase, prices for non-stock items may change without prior notice! Standard prices with 24% VAT.
Video
Swienty DANA api MATIC 2000+ Industrial Automatic Filling Station
Swienty DANA api MATIC 2000+ filling station is an industrial filling device that enables efficient and precise liquid dosing. The heart of the device is a powerful gear pump that ensures accurate filling and easy setup through a modern control panel. All parts in contact with food are made of high-quality food-grade materials and are easy to clean.
Filling Process and Functions
The innovative turntable automatically transports empty jars to the filling unit. The filling process starts automatically when the sensor detects the correct position of the jar. Filled jars then move to the central collection area, enabling a smooth and continuous work process.
Application
DANA api MATIC 2000+ is specially designed for professional industrial use, ideal for precise filling of honey, liquid foods, and other liquids. The device ensures uniform and continuous filling process at high production volumes.
Technical Specifications
- Power consumption: 575W
- Power supply: 90-264VAC 50/60Hz
- Dosing accuracy: +/- 1g
- Pump capacity: 400 l/h
- Noise level: below 70 dB(A)
- Normal filling temperature: up to 40°C
- Hot filling temperature: up to 95°C
- Storable programs: over 20
Capacity and Connections
- Jar diameter: 30-115 mm
- Jar height: 30-190 mm
- Hose connections: 1½" BS on both sides of the pump
Keywords: filling device, honey filler, industrial filling station, automatic filling station, liquid dosing, api matic 2000, swienty equipment, food filler
