Adapter for swing-top bottles

Isobaric Small Bottler for Hobbyists - Swedish Quality Equipment Professional counter-pressure bottling equipment that ensures quality bottling results. With a capacity of 80-90 bottles per hour, it's ideal for small producers and enthusiasts. Technical Specifications: Capacity: 80-90 bottles per hour, Suitable bottle height: 175-310 cm, Bottle mouth diameter: 26 mm, Country of origin: Sweden. Additional Equipment: Swing-top bottle filling nozzle (extra charge 25 EUR). Usage Instructions: Connect the bottler to the CO2 tank and liquid container. Place the bottle under the device. Fill the bottle with CO2 by pressing the black "+" button. Release pressure using the "-" button. Repeat CO2 filling with the "+" button. Repeat the cycle (points 3-4) at least 2 times to achieve optimal CO2 levels. Always press the "+" button before bottling. Open the liquid inlet valve and close it when the bottle is full.

Semi-Automatic Carbonated Beverage Filling System Professional Italian-made semi-automatic filling system, ideal for small producers and beverage industries. The device is designed for filling carbonated beverages (beer, cider, sparkling wine, carbonated water). Technical Specifications: 4 filling nozzles with foam reduction technology, Maximum filling pressure: 5 bar, Power consumption: 0.37kW/220V, Compressed air requirement: 120l/min/6bar, 24V, Device dimensions: 1.92m x 0.8m x 0.40m. Bottle Parameters: Maximum height: 350mm, Maximum diameter: 120mm. Basic Package Includes: Automatic filling system, Safety door, Adjustable filling level tubes, Seal kit for 1" connection valve. Additional Equipment and Features: Pneumatic filling pump, CO2 pre-injection system for foam-free filling, Cleaning solution recirculation system, Automatic cap feeding system, Oxygen removal through water spray during capping, Integrated tank cleaning system, Cleaning mode bottle dummies, Backflow prevention.

Automatic Isobaric Filling Machine for Carbonated Beverages The fully automatic isobaric filling and capping machine is designed for filling carbonated beverages with pressure up to 5 bar. The machine's productivity ranges from 600-850 bottles per hour, depending on the beverage type and bottle format. Technical Specifications Power supply: 400V, power 3kW Compressed air consumption: 120l/min at 7 bar Connections: Tri-clamp standard Bottle Parameters Minimum diameter: 55mm Minimum height: 110mm Maximum diameter: 110mm Maximum height: 350mm Capping System The machine is equipped with an automatic crown cap vibrating hopper and feeding system. Compatible with 26mm or 29mm crown caps. The entire work process is conveniently controlled through a central control panel.

Fully automatic isobaric filling line for bottles and cans The compact rotary multiblock filling system enables efficient isobaric filling for both metal cans and glass bottles. The integrated solution includes a modern crown capping device and can sealing mechanism in a single rotating column. Main features of the equipment: Fully automated work process, compact rotary design, unified filling system for bottles and cans, energy-efficient operation mode, small footprint. The intelligently optimized construction of the filling line ensures maximum productivity with minimal energy costs. The equipment is ideally suited for smaller production spaces where efficient use of space is important.

Cannular Fully Automatic Canning Line - Single Line for Brewers Cannular fully automatic single-line canning system is a modern solution for packaging beer and other carbonated beverages. This compact device is specifically designed for microbreweries producing 1000-5000 liter batches. Benefits of Canning Beer canning ensures: Better product shelf life due to low oxygen levels Complete hermetic sealing Complete light protection Environmentally friendly packaging Convenient outdoor use Technical Specifications Power supply: single-phase 230V Equipped with B64 cartridge (for 202 can bodies) Dimensions: standard pallet size Titanium-coated hardened cartridge (hardness 58-62 dH) Production capacity: up to 15 cans per minute Oxygen level: below 40 ppb Operating Principle and Usage The canning line operates fully automatically: empty cans move independently to the filling position, filling occurs, hermetic sealing is performed, and finished products are ejected. The system requires only one operator and ensures consistent quality throughout the production process. Maintenance and Cleaning The equipment is easy to clean thanks to hose-washable surfaces. Regular maintenance ensures long-term and trouble-free operation. Ideal for small and medium-sized breweries looking to automate their production and ensure high-quality packaging.

NukaTap Counter Pressure Bottle Filler - Professional Beer Filling Equipment NukaTap counter pressure filler is a professional device made entirely of stainless steel, enabling beer filling from kegs to bottles while perfectly preserving the drink's taste, aroma, and carbonation. The device is compatible with all standard beer taps with an internal spout diameter of 10.0 mm or 3/8" universal thread. Main Features and Benefits This compact and durable device includes: Telescopic tubing for quick cleaning, Integrated counter pressure relief valve for precise control, Quick-disconnect carbonation cap, Duotight fittings for beer line connection. Technical Information and Usage The counter pressure filler operates on the pressure difference principle: Bottle is filled with CO2 to keg pressure, Beer flows into the bottle maintaining carbonation, Pressure remains balanced throughout the filling process. Compatibility and Maintenance The device is compatible with most forward-sealing taps, including: NukaTap SS models, NukaTap FC models, Perlick taps. Thanks to its stainless steel construction, the device can be cleaned with various chemicals, ensuring long-term durability and hygiene. The NukaTap counter pressure filler is an ideal choice for both home beer bottling and professional use, maintaining beer quality and taste throughout the entire filling process.
