Self-cleaning semi-automatic filter FUC10 3.5m3/h 35-3000μm
.png){kind=small}
Professionals recommend - producers prefer!
EAN: 2000000025490
Unit: pc
Stock qty: On special order
Delivery time: Eritellimustoode / Please contact / Ota yhteyttä
Delivery time within Estonia for stock items approx. 3-5 working days. NOTE! Due to the rapid price increase, prices for non-stock items may change without prior notice! Standard prices with 22% VAT.
Price:
2765,00 €
Professional Self-Cleaning Juice Filter 3500L/H - German Quality
High-quality stainless steel semi-automatic filter ensures effective filtration of juices, oils, and wines with productivity up to 3500 liters per hour. Made in Germany, this device is perfect for industrial and small-scale production filtration processes.
Main Filter Features:
- Durable stainless steel construction
- Productivity: up to 3500 l/h
- Filter elements: 35-3000μm
- Input, output and cleaning valves: 25mm
Filter Advantages:
- Quick self-cleaning system with manual crank
- Removable V-profile filter element
- Two-part housing with quick clamp
- Low maintenance cost
- Energy-efficient operation
The filter design allows easy maintenance thanks to the quick-release clamp and removable filter element. The V-profile filter element ensures consistent cleaning results and long service life.
100 or 300 micron filter elements are available as standard equipment. For finer filters (35-50 micron), there is an additional cost of €100 + VAT.
The automatic cleaning system collects sediments at the bottom of the filter, which are easily discharged through the bottom valve. The device is ideal for the food industry, thanks to its stainless steel construction and efficient filtration process.
Keywords: juice filter, self-cleaning filter, industrial filter, oil filter, wine filtration device, food industry filter, stainless steel filter, juice industry equipment
| Weight (kg) | 0.000000 |
| High (m) | 0.6 |
| Width (m) | 0.12 |
| Length (m) | 0.12 |
