Rotating filler Troxler Ta5VA 750L/H

SKU: 35161
EAN: 2000000035161
Brand:
Unit: pc
Stock qty: On special order

Delivery time: Eritellimustoode / Please contact / Ota yhteyttä
Price:
5327,00 €
Qty.: - +
   - or -

Video



Professional Sterile Liquid Filling Machine

The fully automatic filling machine TA5VA is designed for precise filling of wines, juices and other liquids. The device is made of high-quality stainless steel and equipped with five professional filling valves and a 26-liter tank.

Main Features

  • Automatic filling process activates when bottle is placed under valve
  • Precise fill level control and automatic stop
  • Rotating upper part with adjustable speed
  • Central liquid control system
  • Adaptable to different bottle sizes

Technical Specifications

  • Filling capacity: 750 liters per hour
  • Tank capacity: 26 liters
  • Bottle diameter: 76-90 mm (expandable to 40-120 mm)
  • Maximum bottle height: 500 mm
  • Power consumption: 60W/230V
  • Dimensions: 500x500x1630 mm
  • Weight: 34 kg

Additional Options

Available with automatic tank filling system with pump and interchangeable centering plates for different bottle sizes. The machine's flexibility allows adjusting the filling process according to your needs.

Keywords: filling machine, juice filler, liquid filler, bottle filler, automatic filling machine, juice filling, wine filling, industrial filler

Weight (kg) 0.000000
High (m) 0
Width (m) 0
Length (m) 0
