Rotating filler Troxler Ta5VA 750L/H

SKU: 35161
EAN: 2000000035161
Brand:
Unit: pc
Stock qty: On special order

Delivery time: Eritellimustoode / Please contact / Ota yhteyttä
Price:
5327,00 €
Qty.: - +
   - or -

Video



Sterile bottler for wines, juices and other liquids. Professional and adjustable bottling valves, the bottle filling process starts automatically when the bottle is pushed under the valve, the filling stops automatically when the desired filling height is reached, the bottle height, bottle diameter and filling height can be easily adjusted, with a stainless steel container. The device can be adjusted according to the height and diameter of the bottle. The filling system can also be used to fill special bottles by changing bottle centering plates, which can be ordered separately. The upper part of the TA5VA models (juice container with valves) rotates with an electric motor at an adjustable speed. The flow of juice to the intermediate storage tank is controlled by the piping inside the central stem, the connecting valve is located in the lower part of the unit. Technical data: power consumption 60W/230V, dimensions 500x500x1630mm, weight 34kg, bottling nozzles 5pcs, productivity/throughput 750l/h, tank size 26l, bottle diameter 76-90mm, max. bottle height 500mm. Additional equipment: automatic filling of the container (26l) with a pump, diameter of bottles 40-120mm.
Weight (kg) 0.000000
High (m) 0
Width (m) 0
Length (m) 0
Similar products
Rotating filler Troxler TA8VA 1000l/h
Sterile bottler for wines, juices and other liquids. Professional and adjustable bottling valves, the bottle filling process starts automatically when the bottle is pushed under the valve, the filling stops automatically when the desired filling height is reached, the bottle height, bottle diameter and filling height can be easily adjusted, with a stainless steel container. The device can be adjusted according to the height and diameter of the bottle. The filling system can also be used to fill special bottles by changing bottle centering plates, which can be ordered separately. The upper part of the TA8VA models (juice tank with valves) rotates with an electric motor at an adjustable speed. The flow of juice to the intermediate storage tank is controlled by the piping inside the central stem, the connecting valve is located in the lower part of the unit. Technical data: power consumption 60W/230V, dimensions 500x500x1800mm, weight 50kg, bottling nozzles 8pcs, productivity/throughput 1000l/h, tank size 50l, bottle diameter 76-90mm, max. bottle height 500mm. Additional equipment: automatic filling of the container (26l) with a pump, diameter of bottles 40-120mm.
SKU: 35178 ,   EAN: 2000000035178 ,   Stock qty: On special order ,   Delivery time: Eritellimustoode / Please contact / Ota yhteyttä ,   Pakend: ,   Hulgipakend:
6715,00 €
Stock qty: On special order
Similar products
TWIN HEAD VERTICAL VOLUMETRIC FILLER FOR DOSES FROM 250 UP TO 5000 ml NO-RETURN VALVES AND NOZZLES WITH GRIDS
Volumetric cylinder dispenser. Doses 250-5000ml..
SKU: 8999359 ,   EAN: 2000000004570 ,   Stock qty: On special order ,   Delivery time: Eritellimustoode / Please contact / Ota yhteyttä ,   Pakend: ,   Hulgipakend:
7996,00 €
Stock qty: On special order
Trolley type 6 filling heads
Stainless gravity cold bottling device for 6 bottles. Made in Italy. Bottling nozzles 15mm; electronic volume sensor to control the pump, setting the amount of liquid on the bottle tips; stainless drain valve; device movable, i.e. on wheels with brakes, productivity 980l/h; Size: 860x1800x900 mm; Weight 80 kg. Additional equipment: pump, foam reduction valve (e.g. when bottling beer), bottling nozzles 17mm, filter, CO2 dosing into an empty bottle..
SKU: 9000222 ,   EAN: 2000000013367 ,   Stock qty: On special order ,   Delivery time: Eritellimustoode / Please contact / Ota yhteyttä
2595,00 €
Stock qty: On special order
hobby bottle filler autom. 3 heads
A simple and primitive bottle opener for 3 bottles. Stainless nozzles and inlet pipe 14mm with float with enameled steel tub. Suitable for bottles only 0.75l..
SKU: E3S ,   EAN: 5420069838744 ,   Stock qty: On special order ,   Delivery time: Eritellimustoode / Please contact / Ota yhteyttä ,   Pakend: ,   Hulgipakend:
101,00 €
Stock qty: On special order
Gravity Filler RF4 with 4 filling valves for bottling as table model made of stainless steel
Stainless bottling device for 4 bottles. adjustment of the amount of liquid on the bottle tips; stainless drain valve; productivity 700l/h; Size: 550x500x1000 mm; Weight 16kg, container 23l. Additional equipment: bottling nozzle for large bottles 43/53 holes.
SKU: 9001490 ,   EAN: 2000000026275 ,   Stock qty: On special order ,   Delivery time: Eritellimustoode / Please contact / Ota yhteyttä ,   Pakend: ,   Hulgipakend:
2650,00 €
Stock qty: On special order
Shaft Seal for GG filler D.011,11x019,05x3,96
Seal for bottling nozzle. On special order, the transport fee from the manufacturer to Estonia will be added..
SKU: 47416 ,   EAN: 2000000047416 ,   Stock qty: On special order ,   Delivery time: Eritellimustoode / Please contact / Ota yhteyttä
12,90 €
Stock qty: On special order
