Pasteurizer 1000l/h D

Energy-Efficient Juice Pasteurizer with Automatic Temperature Control This professional pasteurizer is equipped with a gas burner and efficient heat exchanger, ensuring optimal energy usage in fruit and vegetable juice processing. The device uses innovative multiple heat transfer of flue gases, significantly reducing your production costs. Key Features: Automated temperature control Smart standby mode when juice tank is full Stainless steel (AISI 304) construction Easy maintenance and cleaning with sponge balls Technical Specifications: Processing capacity: 400 L/h (at 80°C) Electric power: 1 kW (230V, 6A) Gas burner power: 30 kW Fuel options: propane, LPG or natural gas Weight: 300 kg Electric cabinet: IP65 protection class Connections: DN 25 Flue gas output: 60/100 mm Available Accessories: Manual bottle filling device Bag in Box filling system with digital scale

Professional Food Pasteurizer: Automatic Solution for Liquid Heat Treatment The fully automatic pasteurizer is specifically designed for safe heat treatment of liquid foods and drinking water. The device meets all modern safety requirements and is made of high-quality AISI 304 stainless steel. Technical Specifications: Capacity: 700 l/h (heating from 20°C to 80°C), Power consumption: 800 W (230 V, 6 A), Heating power: 70 kW, Suitable fuels: propane, LPG or natural gas, Compact dimensions: 850 x 690 x 1700 mm, Weight: 350 kg. Smart Features: Automatic temperature control, Integrated bypass system, Double temperature control, IP65 certified electronics, DN 25 standard connections, 110 mm flue gas outlet. Additional Options and Accessories: Automatic buffer tank above pasteurizer, Semi-automatic Bag in Box filling system, 6-nozzle bottle filling module, Special sponge balls for cleaning. The pasteurizer is equipped with a gas or heating oil boiler and automatic boiler for heating water temperature control. The processed liquid temperature is regulated by a precise bypass valve. The device is easy to maintain thanks to the sponge ball cleaning system. The pasteurizer is perfectly compatible with various filling solutions and is ideal for food industry needs. Minimal maintenance requirements and automated operation ensure an efficient production process.

Juice Pasteurizer Technical Specifications Professional juice pasteurizer is made of high-quality AISI 304 stainless steel (Wnr. 1.4301) and is ideal for industrial juice production. Main Features Capacity: 1200 liters per hour (heating from 20°C to 80°C) Power consumption: 2100 W, 230 V, 6 A Heating power: 120 kW Supported fuel types: propane, LPG, natural gas Weight: 430 kg Dimensions Length: 1210 mm Width: 890 mm Height: 2070 mm Device Benefits IP65 certified electronics DN 25 connections Flue gas outlet: 110 mm diameter Automatic temperature control Built-in bypass system Easy maintenance and cleaning with sponge balls Minimal maintenance requirements Additional Equipment Automatic buffer tank mountable above the pasteurizer Fully automatic control Automatic stop function when juice level is low Compatible with both bottle fillers Semi-automatic Bag in Box filler MKBiB Top 180 6-nozzle bottle filling module Cleaning sponges

Pasteurizer EHA-45: Powerful Juice Processing Equipment for Professionals The EHA-45 pasteurizer is an efficient juice processing unit capable of processing up to 450 liters of juice per hour. The powerful 45kW heating element (400V/80A) ensures a quick and uniform pasteurization process at +80°C. Technical specifications: Compact dimensions: 750x500x1400mm Weight: 200kg Quick heating time: approximately 8 minutes Usage benefits: Juice temperature can be precisely regulated using a manually controlled valve, allowing flexible flow rate adjustment. The unit is equipped with a temperature display ensuring accurate processing. Installation and operation: For efficient operation, the pasteurizer requires an external pump for raw juice feed. The device is ideal for both small producers and larger juice industries, ensuring quality and safe juice processing.

Industrial Pasteurizer EHA-40 - Fully Automatic Juice Processing Equipment Advanced spiral heat exchanger pasteurizer ensures uniform and effective heat treatment of juice. The device design, where the juice pipe is located inside the hot water pipe, enables maximum heat transfer and energy-efficient processing. Technical Specifications: Production capacity: up to 400 liters per hour Processing temperature: +80°C Oil burner power: 48 kW Dimensions: 1000 x 1000 x 1200 mm Weight: 280 kg Main Functions: Fully automatic control center Integrated juice pump Thermostatic temperature control Stepped power regulation The pasteurizer automatically maintains hot water temperature 4-5 degrees higher than the outgoing juice temperature, ensuring optimal pasteurization process. The device power can be adjusted according to production needs by changing the number of active heating elements.

Industrial Juice Pasteurizer EHA-45E: For Precise Juice Processing The high-quality juice pasteurizer EHA-45E is equipped with a modern spiral heat exchanger and powerful hot water pump. The pasteurizer's unique design ensures uniform juice heating thanks to a double-layer pipe system, where the inner juice pipe is surrounded by a hot water pipe. Technical Specifications: Capacity: up to 450 liters per hour Processing temperature: +80°C Power: 45kW (400V) Dimensions: 750 x 850 x 1400 mm Weight: 230 kg Heating time: approximately 8 minutes Smart Solutions: Built-in juice pump Automatic temperature regulation Stepped power control Precise temperature control via thermostat The device's thermostat automatically maintains the hot water temperature 4-5 degrees higher than the outgoing juice temperature, ensuring optimal pasteurization process. The pasteurizer's power can be regulated as needed by activating the required number of heating elements.

Professional Food Pasteurizer: Automatic Solution for Liquid Heat Treatment The fully automatic pasteurizer is specifically designed for safe heat treatment of liquid foods and drinking water. The device meets all modern safety requirements and is made of high-quality AISI 304 stainless steel. Technical Specifications: Capacity: 700 l/h (heating from 20°C to 80°C), Power consumption: 800 W (230 V, 6 A), Heating power: 70 kW, Suitable fuels: propane, LPG or natural gas, Compact dimensions: 850 x 690 x 1700 mm, Weight: 350 kg. Smart Features: Automatic temperature control, Integrated bypass system, Double temperature control, IP65 certified electronics, DN 25 standard connections, 110 mm flue gas outlet. Additional Options and Accessories: Automatic buffer tank above pasteurizer, Semi-automatic Bag in Box filling system, 6-nozzle bottle filling module, Special sponge balls for cleaning. The pasteurizer is equipped with a gas or heating oil boiler and automatic boiler for heating water temperature control. The processed liquid temperature is regulated by a precise bypass valve. The device is easy to maintain thanks to the sponge ball cleaning system. The pasteurizer is perfectly compatible with various filling solutions and is ideal for food industry needs. Minimal maintenance requirements and automated operation ensure an efficient production process.

High-quality flash pasteurizer from Slovenia for food processing. Professional flash pasteurizer designed for processing juices, milk, and other liquid food products. The device ensures optimal pasteurization temperature between 75-85°C, enabling efficient food preservation and bacteria elimination. Technical specifications: Production capacity: 60-90 liters per hour, Height: 1800 mm, Diameter: 400 mm, Electrical power: 6 kW, Electrical connection: 380V. The pasteurizer is equipped with a digital thermostat that allows precise heating water temperature control. Additionally, the device has a visual control system for monitoring the pasteurization process. Ideal for small producers, farm juice makers, and dairy industries requiring reliable and efficient pasteurization solution.

Professional Fruit and Berry Juice Pasteurizer 300L/h Fully automatic electric pasteurizer is ideal for heat treatment of various fruits, berries, and vegetables. The device is designed for processing apples, pears, berries (cloudberries, strawberries, blueberries, elderberries, currants), carrots, herbs, quince, beetroots, sea buckthorn, rowan berries, and onions. Main Features: Fully automatic flow-through type, Dual temperature control (heat exchanger and outlet), Automatic bypass system for temperature regulation, Easy cleaning with sponge balls, Minimal maintenance required. Technical Specifications: Capacity: 300 liters per hour (20°C to 80°C), Power: 28 kW, 400 V, 32 A (three-phase), Stainless steel: WNr. 1.4301, AISI 304, IP65 certified electronics, DN 25 connections, 2 thermometers. Dimensions and Weight: Length: 1539 mm, Width: 642 mm, Height: 1850 mm, Weight: 230 kg. Optional Accessories: BiB filling modules, Bottle filling modules, Manual BiB filler with digital scale, Dual-head bottle filling module, Cleaning sponges.

50L Professional Juice Pasteurizer in Stainless Steel This industrial pasteurizer is specifically designed for efficient processing of larger quantities of juices. The device ensures safe and high-quality pasteurization of juices while maximally preserving vitamins and nutrients. Key Features of the Pasteurizer: Capacity: 50-liter stainless steel pot, Integrated heat exchanger spiral for uniform juice processing, Precise output thermometer (temperature range up to 120°C), Adjustable juice outflow system, Removable DIN-standard compliant connections. Operating Principle: The pasteurization process occurs through the heat exchanger spiral, where heated water uniformly warms the flowing juice. To ensure the quality of pasteurized juice, immediate cooling after bottling is recommended. Applications: Ideal for small producers and juice industries who value: Preservation of natural juice flavor, Maximum retention of nutrients, Efficient production process, High hygiene standards.

Industrial Juice Pasteurizer EHA-45E: For Precise Juice Processing The high-quality juice pasteurizer EHA-45E is equipped with a modern spiral heat exchanger and powerful hot water pump. The pasteurizer's unique design ensures uniform juice heating thanks to a double-layer pipe system, where the inner juice pipe is surrounded by a hot water pipe. Technical Specifications: Capacity: up to 450 liters per hour Processing temperature: +80°C Power: 45kW (400V) Dimensions: 750 x 850 x 1400 mm Weight: 230 kg Heating time: approximately 8 minutes Smart Solutions: Built-in juice pump Automatic temperature regulation Stepped power control Precise temperature control via thermostat The device's thermostat automatically maintains the hot water temperature 4-5 degrees higher than the outgoing juice temperature, ensuring optimal pasteurization process. The pasteurizer's power can be regulated as needed by activating the required number of heating elements.
