Gasket for maxi plate 80

Professional Maxi 80 Stainless Steel Heat Exchanger The Maxi 80 heat exchanger is made of high-quality Aisi 304 stainless steel (18/10), ensuring long-term durability and reliability. Technical Data: Connections: 1"1/4 Maximum working pressure: 10 bar Plate surface: 0.08 m² Plate liquid volume: 0.25L Single plate weight: 0.5 kg Total weight: 50 kg Number of plates: 22 Kit Includes: Stainless steel adapter F 1"¼ and 3/4" M 4 stainless steel hose connections 20 mm with 3/4"F nut Main Advantages: High heat exchange coefficient Liquids do not mix with each other Flexible system with possibility to add plates Long service life due to plate regeneration and component replacement options Complies with European Directive 97/23/EC (PED) Maintenance and Cleaning: Device cleaning is recommended immediately after use: Rinse with hot water Clean with OXI or other alkaline cleaner Rinse thoroughly with water Store in a clean and dry place Disinfection: Before next use, circulate water and acidic cleaner or OXI solution in the device. Always use protective equipment: gloves, goggles, and mask.

Ground-mounted heat exchanger clamp - efficient cooling system The durable heat exchanger clamp is specially designed for ground mounting and fixation. This strong mounting system ensures stable positioning and secure installation of the heat exchanger. Benefits of the heat exchanger clamp: Simple and quick ground installation. Strong fixation during cooling process. Durable construction for long-term use. Optimal cooling system performance. The ground-mounted heat exchanger clamp is an essential component for ensuring an efficient cooling process. It increases the reliability of the cooling device and ensures consistent cooling efficiency.

Openable Plate Heat Exchanger - Expandable and Easy-to-Maintain Solution High-quality stainless steel plate heat exchanger ensures efficient heat transfer when cooling the wort. The special design of the device allows for convenient cleaning of cooling plates and adding additional plates when needed. Main advantages: Easy maintenance thanks to openable design Possibility to increase system capacity with additional plates Made of durable stainless steel Includes quality gaskets By adding plates, you can increase the heat exchanger's performance according to your production needs. The device is delivered ready for immediate use with stainless steel plate and gasket. Technical info: Material: stainless steel Expandable system Ready-to-use kit

Energy-Efficient Stainless Steel Heat Exchanger for Food Industry Food industry certified stainless steel heat exchanger with surfaces smoothened using laser technology. The self-cleaning design and complete disassembly capability ensure easy maintenance. Technical Specifications: Cooling/heating water flow: 2750 l/h Cooled/heated liquid flow: 900 l/h Temperature difference: 3 degrees Energy savings: up to 50% Features: Self-cleaning technology Fully dismantlable Food-grade material Laser-processed surfaces Different models available with flow rates up to 21,000 l/h. For optimal results, the inlet flow should be three times greater than the raw material flow.

V4A stainless steel cooling and heating pipe 2.5 meters. High-quality stainless steel pipe, ideal for cooling and heating systems in juice, beer, and wine industries. The pipe is exactly 2.5 meters long, made of durable V4A (AISI 316) stainless steel. Product features: Material: V4A stainless steel (AISI 316), Length: 2.5 meters, Corrosion resistant, Compliant with food industry standards, High temperature tolerance. The pipe is specially treated to ensure maximum resistance to both hot and cold liquids. Perfect for industrial use in juice production, brewing industry, and other food industry sectors.

Industrial 36-Plate Stainless Steel Heat Exchanger. Powerful stainless steel heat exchanger certified for food industry, ideal for rapid cooling or heating of juice, beer and other beverages. The device consists of 36 separate plates that ensure maximum heat exchange efficiency. Technical Specifications: Material: food-safe stainless steel, Number of plates: 36, Connections: 3/4" external thread nuts, Hose connections: for 12mm hose. Performance and Usage: The heat exchanger can cool 60 liters of high-temperature (+95°C) liquid to 20°C in just 10 minutes using 10°C coolant. The device is versatile, functioning as both cooling and heating system. Applications: Juice production, Beer brewing, Dairy industry, Food processing. The stainless steel heat exchanger is durable, maintenance-free and ensures quick and uniform temperature regulation. Compact design allows for easy installation and use.

Professional Maxi 80 Stainless Steel Heat Exchanger The Maxi 80 heat exchanger is made of high-quality Aisi 304 stainless steel (18/10), ensuring long-term durability and reliability. Technical Data: Connections: 1"1/4 Maximum working pressure: 10 bar Plate surface: 0.08 m² Plate liquid volume: 0.25L Single plate weight: 0.5 kg Total weight: 50 kg Number of plates: 22 Kit Includes: Stainless steel adapter F 1"¼ and 3/4" M 4 stainless steel hose connections 20 mm with 3/4"F nut Main Advantages: High heat exchange coefficient Liquids do not mix with each other Flexible system with possibility to add plates Long service life due to plate regeneration and component replacement options Complies with European Directive 97/23/EC (PED) Maintenance and Cleaning: Device cleaning is recommended immediately after use: Rinse with hot water Clean with OXI or other alkaline cleaner Rinse thoroughly with water Store in a clean and dry place Disinfection: Before next use, circulate water and acidic cleaner or OXI solution in the device. Always use protective equipment: gloves, goggles, and mask.

Openable Plate Heat Exchanger - Expandable and Easy-to-Maintain Solution High-quality stainless steel plate heat exchanger ensures efficient heat transfer when cooling the wort. The special design of the device allows for convenient cleaning of cooling plates and adding additional plates when needed. Main advantages: Easy maintenance thanks to openable design Possibility to increase system capacity with additional plates Made of durable stainless steel Includes quality gaskets By adding plates, you can increase the heat exchanger's performance according to your production needs. The device is delivered ready for immediate use with stainless steel plate and gasket. Technical info: Material: stainless steel Expandable system Ready-to-use kit

Ground-mounted heat exchanger clamp - efficient cooling system The durable heat exchanger clamp is specially designed for ground mounting and fixation. This strong mounting system ensures stable positioning and secure installation of the heat exchanger. Benefits of the heat exchanger clamp: Simple and quick ground installation. Strong fixation during cooling process. Durable construction for long-term use. Optimal cooling system performance. The ground-mounted heat exchanger clamp is an essential component for ensuring an efficient cooling process. It increases the reliability of the cooling device and ensures consistent cooling efficiency.

Energy-Efficient Food Industry Heat Exchanger - Self-Cleaning and Efficient Stainless steel heat exchanger specially designed for the food industry ensures maximum efficiency and hygiene. Laser-processed smooth surfaces make the device self-cleaning and allow for complete disassembly. Technical Specifications: Cooling/heating water flow: 15,840 l/h Cooled/heated liquid flow: 5,440 l/h Temperature difference: 4 degrees Energy savings: up to 50% To achieve optimal temperature, the inlet flow must be three times greater than the raw material flow. We offer different models with capacity up to 21,000 l/h. Main Advantages: Food industry certified materials Easy maintenance thanks to self-cleaning technology Complete disassembly capability Significant energy savings

Professional Maxi 80 Plate Heat Exchanger for Food Industry High-quality Maxi 80 plate heat exchanger is manufactured from Aisi 304 stainless steel (18/10) meeting food industry standards. The device enables efficient heat transfer between two liquids while ensuring their complete separation. Standard Equipment: Stainless steel interface F 1"¼ and 3/4" M, 4 stainless steel hose connections (20 mm, with 3/4" F nut), 60 heat exchange plates. Technical Specifications: Maximum power: 80 kW, Maximum working pressure: 10 bar, Single plate area: 0.08 m², Plate liquid volume: 0.25 L, Plate weight: 0.5 kg, Total weight: 50 kg. Advantages and Features: High heat exchange efficiency, Complete liquid separation, Expandable number of plates, Easy maintenance and part replacement, Compliant with EU directive 97/23/EC (PED). Maintenance and Cleaning: The heat exchanger requires immediate cleaning after use: Rinse with hot water, Clean with OXI or other alkaline cleaner, Finally rinse with clean water. Disinfect the device before next use with acidic cleaner or OXI solution. Use protective equipment during cleaning: gloves, goggles, and mask. Store the device in a clean and dry place.

Stainless Steel Cooling Panel for Rapid Liquid Cooling High-quality AISI 304 stainless steel cooling panel designed for efficient cooling of various liquids. The panel is equipped with 290mm connection pipes and is ideal for installation in tanks. Technical Specifications: Dimensions: 370x1000mm, Cooling surface: 0.74m², Pipes: 290mm, Weight: 6.5kg, Connection: DN1/2, Maximum working pressure: 4 bar. Installation and Use The cooling panel is easy to install - place the panel in the liquid to be cooled and connect the cooling system fittings. Thanks to food industry compliant AISI 304 steel, the device is also suitable for cooling liquids that come into contact with food. Due to its large cooling surface (0.74m²), the panel ensures fast and uniform cooling process. Durable construction and quality materials guarantee long service life of the device.

Industrial 36-Plate Stainless Steel Heat Exchanger. Powerful stainless steel heat exchanger certified for food industry, ideal for rapid cooling or heating of juice, beer and other beverages. The device consists of 36 separate plates that ensure maximum heat exchange efficiency. Technical Specifications: Material: food-safe stainless steel, Number of plates: 36, Connections: 3/4" external thread nuts, Hose connections: for 12mm hose. Performance and Usage: The heat exchanger can cool 60 liters of high-temperature (+95°C) liquid to 20°C in just 10 minutes using 10°C coolant. The device is versatile, functioning as both cooling and heating system. Applications: Juice production, Beer brewing, Dairy industry, Food processing. The stainless steel heat exchanger is durable, maintenance-free and ensures quick and uniform temperature regulation. Compact design allows for easy installation and use.

Stainless Steel Spiral Cooler for Distillation Equipment High-quality stainless steel spiral cooler ensures efficient and rapid cooling process. The device is equipped with a durable 9.5mm cooling tube and a compact 26.5cm diameter spiral core. Technical Specifications: Total height: 55 centimeters Spiral height: 19 centimeters Cooling tube: 9.5mm stainless steel Spiral core diameter: 26.5cm Connections: Gardena watering hose fittings Warranty: 3 years The cooling capacity allows cooling 50 liters of liquid from 100 degrees to 20 degrees in just 20 minutes when the coolant temperature is 13 degrees. The stainless steel construction ensures long-term durability and hygiene. The practical Gardena-type connection system makes cooler installation and maintenance easy. Due to its compact dimensions, the device is ideal for both home and professional use.

Ground-mounted heat exchanger clamp - efficient cooling system The durable heat exchanger clamp is specially designed for ground mounting and fixation. This strong mounting system ensures stable positioning and secure installation of the heat exchanger. Benefits of the heat exchanger clamp: Simple and quick ground installation. Strong fixation during cooling process. Durable construction for long-term use. Optimal cooling system performance. The ground-mounted heat exchanger clamp is an essential component for ensuring an efficient cooling process. It increases the reliability of the cooling device and ensures consistent cooling efficiency.

Professional Maxi 80 Plate Heat Exchanger for Food Industry High-quality Maxi 80 plate heat exchanger is manufactured from Aisi 304 stainless steel (18/10) meeting food industry standards. The device enables efficient heat transfer between two liquids while ensuring their complete separation. Standard Equipment: Stainless steel interface F 1"¼ and 3/4" M, 4 stainless steel hose connections (20 mm, with 3/4" F nut), 60 heat exchange plates. Technical Specifications: Maximum power: 80 kW, Maximum working pressure: 10 bar, Single plate area: 0.08 m², Plate liquid volume: 0.25 L, Plate weight: 0.5 kg, Total weight: 50 kg. Advantages and Features: High heat exchange efficiency, Complete liquid separation, Expandable number of plates, Easy maintenance and part replacement, Compliant with EU directive 97/23/EC (PED). Maintenance and Cleaning: The heat exchanger requires immediate cleaning after use: Rinse with hot water, Clean with OXI or other alkaline cleaner, Finally rinse with clean water. Disinfect the device before next use with acidic cleaner or OXI solution. Use protective equipment during cleaning: gloves, goggles, and mask. Store the device in a clean and dry place.
