Gas Line Manifold with MFL Thread, 4-Way Output

Gas line distribution manifold with 4 outputs (MFL thread) duotight compatible

Product Description

These gas distribution manifolds are designed to work with pressures up to 6.9 bar (100 psi) and include 4 gas line outputs with 4 x 1/4-inch (6.35 mm) ball valves with MFL thread. This is a simple and convenient way to create multiple gas lines from a single gas line.

You can additionally attach a gas ball lock post with a 1/4-inch (6.35 mm) bulkhead if you want to easily disconnect and reconnect the gas line. Alternatively, you can also install Duotight 8 mm to 1/4-inch (6.35 mm) push-in fittings on this manifold. However, this would lose the advantage of the built-in check valve and the ability to isolate each gas line separately.

NOTE: This product is not suitable for beer or other beverages. For gas only.

Please note that due to the check valve mechanism, the pressure drops in these manifold ball valves by approximately 0.14 bar (2 psi). The regulator needs to be set about 0.14 bar (2 psi) higher than the desired pressure in the keg.

Operating Principle

The distribution manifold allows connecting one gas source to four different gas lines. Built-in check valves prevent gas backflow, and ball valves allow individual line closure or opening. This is an ideal solution for simultaneously supplying gas to multiple kegs or devices, ensuring uniform and adjustable gas flow.

Technical Specifications

• Number of outputs: 4
• Thread type: MFL (Male Flare)
• Thread size: 1/4-inch (6.35 mm)
• Maximum operating pressure: 6.9 bar (100 psi)
• Valve type: Ball valves with integrated check valves
• Pressure drop: Approximately 0.14 bar (2 psi)
• Compatibility: Duotight fittings, gas ball lock posts
• Application: Gas distribution only (not for liquids)
