500L Mixing blender with adjustable legs, stainless steel
.png){kind=small}
Professionals recommend - producers prefer!
EAN: 20000000543013
Unit: pc
Stock qty: On special order
Delivery time within Estonia for stock items approx. 3-5 working days. NOTE! Due to the rapid price increase, prices for non-stock items may change without prior notice! Standard prices with 24% VAT.
Mixing tank 500L with adjustable legs, stainless steel
The mixing tank is made of AISI 304 stainless steel 18/10. The interior surface has a mirror finish, while the exterior has a patterned finish with satin welds. The tank bottom is conical with a 10° slope. The support base is made of stainless steel with adjustable legs.
The unit is equipped with a 0.5 hp (0.37 kW) motor operating on 380V power. The mechanical speed controller allows rotation speeds between 14-140 rpm. The mixer is equipped with three height-adjustable stainless steel (AISI 304) mixing blades.
For inspection, there is a hinged lid with safety grid. For complete tank drainage, a stainless steel butterfly valve, DIN 40 MG/40 DIN (female) is installed.
Technical specifications:
- Capacity: 500 liters
- Conical bottom slope: 10°
- Tank diameter: 800 mm
- Cylinder height: 1000 mm
- Dimensions: width 1070 mm, depth 880 mm, height 1550 mm
- Total height: 1800 mm
- Number of internal blades: 3
- Shaft rotation speed: 14-140 rpm
- Power supply: 380V
Additional equipment:
- Coaxial rubber blade pump (Euro 30 model) for product circulation and better homogeneity
- Pump motor: 0.75 hp (0.48 kW), 380V, 900 rpm
- Pump equipped with piping and valves for tank filling and emptying
- Electric control panel for pump and mixer control, equipped with emergency switch
Applications:
This professional mixing tank is designed for mixing various liquids and semi-thick substances in food industry, chemical industry, or pharmaceutical industry. Adjustable mixing speed allows customizing mixing intensity according to product requirements. Stainless steel construction ensures long service life and easy cleaning.
Keywords: mixing tank, industrial mixer, stainless steel mixer, food industry equipment, chemical industry mixer, stainless steel tank, 500L mixer, adjustable mixer, industrial mixer, AISI 304 mixer, liquid mixing equipment, homogenization equipment, industrial mixing tank, conical bottom mixer, mixer with adjustable legs
| Weight (kg) | 0.000000 |
| High (m) | 1.8 |
| Width (m) | 0.88 |
| Length (m) | 1.07 |
29,20 €
